See full details below.
Video Resolution & Quality
Both the front and rear camera record in full HD 1080P @ 30 FPS to provide some of the highest quality footage available from a dash camera. The 140° viewing angle ensures the camera captures an extensive view of the road ahead and behind.
The sample video provides an indication of what the video will look like, be aware that YouTube compression can decrease the video quality so make sure that you have it set to the highest resolution.
Thinkware F770 Recording Modes
Continuous Recording– The F770 will begin recording automatically when the engine is switched on and will continue in this mode during normal driving conditions.
Event Recording– If the G-Shock sensor is triggered a 10 second pre and post-impact video clip is saved.
Manual recording– When the REC button is pressed a manual event is created.
Parked Recording Mode
The Thinkware F770 has a brand new parking mode, which now consists of two settings Time-Lapse and motion detection. Please note that you can only have one of these modes active at a time.
Time-lapse– The F770 will record at 1fps when the vehicle is parked, this means you’ll be collecting crisp clear video many hours after leaving the vehicle. If the G-shock sensor is triggered a 6 minute 30fps video file will be created showing 3 minutes before and after the incident.
Motion Detection– The F770 will only record footage if it detects movement near the vehicle then a 20 second video clip will be created showing the 10 seconds before and after the movement was detected, the same will happen if an impact is detected.
Thinkware F770 Recording Times
Recording in full HD @ 30FPS
|SD Card Capacity||Front and rear||Front only|
|16GB||62 Minutes||124 Minutes|
|32GB||124 Minutes||248 Minutes|
|64GB||248 Minutes||496 Minutes|
When you connect your IOS or Android device to the camera over Wi-Fi you are able to watch the camera live, review old footage, download footage and change the settings of the camera to your preference.Through the use of the GPS the camera is able to locate the vehicle and monitor the speed and direction of travel to provide court admissible evidence if an accident occurs.
The Thinkware F770 has two advanced warning systems, Lane departure warning system (LDWS) and Forward collision warning system (FCWS). For these features to be used the GPS needs to be working on the camera and the vehicle must be travelling a minimum of 30 MPH. These warning systems are optional and can be disabled in the settings menu of the Thinkware app.
LDWS When the vehicle is leaving its lane an audible warning will be issued to notify the driver.
FCWS This notifies the driver through an audible warning that the vehicle in front is slowing down or stopped to ensure that you do not have a rear-end collision.
In every box the following items come packaged:
- Brand – Thinkware
- Model – F770
- Front Camera – Yes
- Screen – No
- HD/Video Resolution – 1080p 1920 x 1080
- Video Frame Rate – 30fps
- Codec – H.264
- File Format – MP4
- Video Playback – Via IOS/Android App or PC/Mac Software
- Viewing Angle – Diagonal 140°
- Sensor – Sony Exmore CMOS Sensor 2.19 MP
- Internal Mic (Sound Recorded) – Yes, can be muted
- Memory Card Included – Yes, 32GB Micro SD Card Class 10
- Memory Capacity – 64GB SD Card Class 10
- WiFi – Yes
- Software – Thinkware viewer
- Software Compatibility – Windows/Mac
- Mobile App – Yes, Thinkware app for IOS & Android
- Speed Camera Alerts – Yes
- Lane Departure Warning System (LDWS) – Yes
- Front Collision Warning System (FCWS) – Yes
- Removable Camera – Yes
- Internal Battery – No
- G-Sensor – Yes
- Parking Mode – Yes, requires hardwire cable
- Photo Mode – No
- Built in GPS – Yes
- GPS Mapping – Yes
- Speed Stamp – Yes, only visible via software or app
- Auto Event Recording – Yes
- Auto start/stop rec – Yes
- Date/Time Stamp – Yes
- Overwrite Recording – Yes
- Manual Recording – Yes
- One Touch Formatting – Yes
- Tone Alerts – Yes
- Spoken Alerts – Yes
- Super Night-vision – Yes
- Operating Temperatures – -10° ~ 60°C
- Waterproof – No
- Dimensions – 110mm (W) x 60mm (D) x 31.75mm (H)
- Manufacturer Warranty – Dash Cam 1 Year, SD Card 6 Months
